Colled Rolled Flat Bar 1018 - 5/16 Inch X 3/4 Inch
| Weight | 0.796700 |
|---|---|
| bobco_dimensions_width | 0.75 |
| bobco_dimensions_length | 144 |
| bobco_thickness | 0.3125 |
| price_21to50 | 0 |
| price_11to20 | 0 |
| price_6to10 | 0 |
| addon_charges_fraction | 2 |
| addon_charges_percentage | 20 |
| addon_charges_simple | 5 |
| MAX LENGTHS | 12 |
| FULL LENGTH PRICE | 33.09 |
| Thickness | 0.3125 |
| Dimension Length | 144.000000 |
| Dimension Width | 0.750000 |
| Dimension Height | 0.312500 |
1018 Cold Rolled Flat Bar - 3/4" x 5/16" x 144"
This 3/4" x 5/16" 1018 Cold Rolled Flat Bar offers tight dimensional accuracy and a smooth, scale-free surface. Certified to ASTM A108, it combines 63,800 PSI tensile strength with good weldability and machinability, making it ideal for precision fabrication and component manufacturing. In stock Los Angeles.
- 1018 Steel Construction
- ASTM A108 Certified
- 63,800 PSI Tensile Strength
- Good Machinability & Weldability
1018 is a low-carbon steel manufactured through a cold drawing process, which increases its strength and provides a superior surface finish compared to hot rolled steel. It complies with ASTM A108 standards and offers an excellent balance of strength, ductility, and toughness. This grade is easily welded and machined, and is particularly well-suited for case hardening (carburizing) applications.
As a small-profile flat bar, this 3/4" width is perfectly suited for applications requiring precision and moderate strength, such as fabricating custom mounting brackets, support straps, shims for alignment, and components for small equipment frames where a clean finish is important.
Specifications
- Material: 1018 Steel
- Standards: ASTM A108
- Strength/Tensile: 63,800 PSI
- Dimensions: 3/4" Width x 5/16" Thickness x 144" Length
- Finish: Cold Drawn
- Certifications: MTR Available
Applications
- Fabrication: Brackets and straps - its tight tolerances ensure precise fit-up.
- Machinery: Levers and linkages - good machinability allows for creating accurate small parts.
- Fixturing: Alignment shims - consistent thickness is critical for precision jigs.
- Automotive: Small mounting tabs and supports - easily welded into assemblies.
Target Users
Fabricators, machinists, and maintenance technicians rely on 1018 cold rolled flat bar for its versatility and clean finish in general manufacturing and repair applications throughout the Los Angeles area.
Finish Options
This product comes standard with a cold drawn finish, characterized by a smooth, scale-free, and often slightly oily surface with tight dimensional control. For specific project requirements, other finishes such as grinding or plating may be achieved through secondary processing. Contact our Los Angeles sales team for custom finish inquiries.
How to Measure
Flat bar is measured by its Width (A) and Thickness (B). The width is the larger of the two cross-sectional dimensions.
Example: To order this flat bar, specify "1018 Cold Rolled Flat Bar, 3/4" x 5/16" x 144" length".
Order Checklist
- Product name and required dimensions (3/4" x 5/16" x 144")
- Material specification and quantity
- Confirm grade (1018) meets requirements
- Surface finish requirements (Cold Drawn)
- Certifications required (Mill Test Report)
- Special handling or delivery requirements
Quick Facts
- Product
- 1018 Cold Rolled Flat Bar - 3/4" x 5/16" x 144"
- Material
- 1018 Steel
- Standards
- ASTM A108
- Key Properties
- 63,800 PSI tensile, good machinability, good weldability
- Primary Applications
- Brackets, straps, shims, small frame stock
- Location
- Los Angeles warehouse - Same-day pickup available
Available Sizes
We stock 1018 Cold Rolled Flat Bar in widths from 1/4" to 12" and thicknesses from 1/8" to 2". This 3/4" x 5/16" size is available for immediate pickup in Los Angeles.
Custom cutting services available.
Contact for Sizing-
Colled Rolled Flat Bar 1018 - 5/16 Inch X 3/4 Inch$10.75
-
-
-
-
