Colled Rolled Flat Bar 1018 - 3/16 Inch X 6 Inch
| Weight | 3.750000 |
|---|---|
| bobco_dimensions_width | 6 |
| bobco_dimensions_length | 144 |
| bobco_thickness | 0.1875 |
| price_21to50 | 0 |
| price_11to20 | 0 |
| price_6to10 | 0 |
| addon_charges_fraction | 2 |
| addon_charges_percentage | 20 |
| addon_charges_simple | 10 |
| MAX LENGTHS | 12 |
| FULL LENGTH PRICE | 124.58 |
| Thickness | 0.1875 |
| Dimension Length | 144.000000 |
| Dimension Width | 6.000000 |
| Dimension Height | 0.187500 |
Colled Rolled Flat Bar 1018 - 3/16 Inch X 6 Inch
A 6" x 3/16" 1018 Cold Rolled Steel Flat Bar, compliant with ASTM A108 standards. This bar features tight dimensional tolerances and a clean, smooth surface finish from the cold drawing process. With 63,800 PSI tensile strength, it's ideal for precision fabrication. In stock Los Angeles.
- 1018 Steel Construction
- ASTM A108 Certified
- 63,800 PSI Tensile Strength
- Excellent Machinability
1018 Cold Rolled Steel is a low-carbon grade manufactured through a cold drawing process, resulting in superior dimensional accuracy and a scale-free surface. It meets ASTM A108 specifications and provides a good balance of strength, ductility, and toughness. With a tensile strength of 63,800 PSI, it is easily machined and welded, making it a versatile choice for general fabrication.
As a large-format flat bar, this 6-inch wide profile is perfectly suited for applications requiring stability and a broad mounting surface. Common uses include machine base plates, heavy structural bracing, die components, and support brackets where significant load distribution is necessary.
Specifications
- Material: 1018 Cold Rolled Steel
- Standards: ASTM A108
- Strength/Tensile: 63,800 PSI
- Dimensions: 6" Width x 3/16" Thickness x 144" Length
- Finish: Cold Drawn
- Certifications: MTR Available
Applications
- Industrial Machinery: Base plates - provides a flat, stable foundation for heavy equipment.
- Fabrication: Heavy structural bracing - offers high strength and rigidity for frame construction.
- Tool & Die: Die components and fixtures - excellent machinability allows for precise shaping.
- Construction: Mounting plates and gussets - wide profile distributes loads effectively.
Target Users
Fabricators, machinists, and structural engineers rely on 1018 cold rolled flat bar for its reliable performance and clean finish in industrial and construction projects throughout the Los Angeles area.
Finish Options
This product comes standard with a cold drawn finish, providing a smooth, scale-free surface and tight dimensional control. For specific project requirements, other finishes such as grinding or polishing may be available via special order. Contact our Los Angeles sales team for custom finish inquiries.
How to Measure
Flat bar is measured by its Width (A) and Thickness (B). Use calipers to ensure accuracy for both dimensions.
Example: To order this flat bar, specify "1018 Cold Rolled Flat Bar, 6" x 3/16" x 144" length".
Order Checklist
- Product name and required dimensions (6" x 3/16" x 144")
- Material specification and quantity
- Confirm grade (1018) meets requirements
- Surface finish requirements (Cold Drawn)
- Certifications required (Mill Test Report)
- Special handling or delivery requirements
Quick Facts
- Product
- Colled Rolled Flat Bar 1018 - 3/16 Inch X 6 Inch
- Material
- 1018 Cold Rolled Steel
- Standards
- ASTM A108
- Key Properties
- 63,800 PSI tensile, Excellent Machinability, Good Weldability
- Primary Applications
- Base plates, structural bracing, die components
- Location
- Los Angeles warehouse - Same-day pickup available
Available Sizes
We stock 1018 Cold Rolled Flat Bar in widths from 1/4" to 12" and thicknesses from 1/8" to 2". This 6" x 3/16" size is available for immediate pickup in Los Angeles.
Custom cutting services available.
Contact for Sizing-
Colled Rolled Flat Bar 1018 - 3/16 Inch X 6 Inch$28.99
-
-
-
-
